Battery specification: 20S21P
Nominal voltage：64V
Nominal capacity：73.5Ah
Charging voltage: 72V
Charging current: ≤20A
Discharging current: 40.0A
Instant discharging current: 100.0A
End-off voltage: 50.0V
Internal resistance: ≤150mΩ
Battery weight: 52Kg
Product dimension: 450.0*460.0*192.5.0(mm)max
Charging temperature：0～45℃
Discharging temperature: -20～60 ℃
Storage temperature: -20～45℃
Battery case: general industrial grade
Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection, etc.
Application field: industrial robot
Product features
1. Communication protocol: CAN communication protocol can transmit product data.
2. Cell characteristics: power type LiFePO4 battery pack
3. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
4. High current output ensures the safety of industrial robots in fire fighting.
