Item项目 |
Specification 标准 |
Remark 备注 |
|
|
Typical Capacity |
3400mAh |
0.2C discharge capacity |
|
|
Minimum Capacity |
3300mAh |
|
|
|
Internal Impedance |
≤20mΩ |
By AC 1 kHz |
|
|
Nominal Voltage |
3.20 V |
|
|
|
Cell Weight |
87.0±3.0g |
contain package |
|
|
Energy Density能量密度 |
125Wh/kg |
|
|
|
End-of-charge Voltage |
3.6V |
At CC mode |
|
|
End-of-discharge Voltage |
2.0V |
At CC mode |
|
|
Standard Charging |
0.5C CC/CV, cut off 0.01C |
180min |
|
|
Standard Discharging |
0.5C CC, cut off 2.0V |
|
|
|
Max Continuous Charge |
0.2C |
0~10℃ |
|
|
|
0.5C |
10~10℃ |
|
|
|
1.5C |
20~45℃ |
|
|
Max Continuous Discharge |
3C |
|
|
|
Cycle Life |
≥3000 cycles |
+0.5C/-0.5C |
|
|
Operating |
Charging Temperature |
0~45℃ |
|
|
|
Discharging Temperature |
-20~60℃ |
|
|
|
Storage Temperature |
-20～45℃ |
3month（3 个月） |
|
|
|
-10～25℃ |
6month（6 个月） |
|
Shelf Life |
1year |
||
